Specifications
Xtreme Manufacturing offers the largest and most comprehensive line of heavy-duty and high capacity telehandlers in North America. Designed to deliver a long-working life with low total ownership costs, all Xtreme products are built around a core focus on safety, reliability and serviceability, and are backed by an industry-leading 10 year – 5 year – 2 year warranty. Innovative features.
- Telehandler Reach Forklift, 50 ft.-56 ft., 12,000 lbs. Combine the lifting power of a forklift and the utility of the crane with this telescopic telehandler. This unit can carry up to 12,000 lbs. Of materials and reach up to 56' for heavy-duty jobs. We have multiple steering modes available.
- Used Forklifts Versus New Forklifts. There are many things to consider when deciding to forklift more than a few hours every day for heavy lifting, a new although more affordable, are better suited to handle less frequent use have greater capabilities and dealers generally offer warranties with which is why most companies purchase used forklifts versus new type and the engine type you need.
Engine
Gross Power (Basic) 142.1 hp
Weights
Operating Weight 35860 lb
Operating Specifications
Rated Load Capacity 12000 lb
Maximum Lift Height 54.3 ft
12k Forklift For Rent
Load at Max Height – Stabilizers Down 5000 lb
Load at Max Height – Stabilizers Up 4000 lb
Maximum Forward Reach 42.5 ft
Load at Max Reach – Stabilizers Down 3500 lb
Top Travel Speed 20.4 mph
Load at Max Height 5000 lb
Load at Max Reach 3498.73 lb
Dimensions
Height 8.4 ft
Width 8.4 ft
Wheelbase 12 ft
Length to Fork Face 20.8 ft
Ground Clearance 19 in
Turning Radius over Tires 14 ft
Tires
Standard 17.50 x 25 – 12 PR
Hydraulic System
Pump Type Load sensing piston
Service Refill Capacities
Fuel Tank 38 gal
Hydraulic Tank 63 gal
12k Forklift Chart
Hydraulic System 63 gal
Boom Performance
Boom Up 16 Seconds
Boom Down 14.8 Seconds
12k Forklift For Sale
Tele In 13.4 Seconds
Tele Out 17.2 Seconds
12k Forklifts For Sale
Drawbar Pull (Basic) 20000 lb
Brakes
Parking Brake mechanical on front axle
